Mounting method
DIN rail (top hat rail) 35 mm
-
Width in number of modular spacings
2
-
System configuration
TN-S, TT
-
Nominal discharge surge current (8/20) [kA]
20
-
Nominal voltage AC [V]
275
-
Max. continuous voltage AC [V]
275
-
Voltage protection level L-N [kV]
1.4
-
Voltage protection level N-PE [kV]
-
-
Construction size
2 modular spacing
-
Max. conductor cross section solid (solid, stranded) [mm²]
35
-
Max. conductor cross section flexible (fine-strand) [mm²]
35
-
With remote signalling contact
No
-
Integrated backup fuse
No
-
Signalling at the device
Optic
