Residual Current Circuit Breaker Ex9L-N 4P 40A A 100mA | Optonica LED

Residual Current Circuit Breaker Ex9L-N 4P 40A A 100mA SKU: 108366

Power
Light color
Send quotation
  • Brand
    NOARK
  • IP
    20
  • EAN Code
    8592765083661
  • Operating Frequency
    50Hz
  • Mounting method
    DIN rail
  • Width in number of modular spacings
    4
  • Power loss [W]
    15.3
  • Number of poles (total)
    4
  • Nominal rated voltage [V]
    400
  • Nominal rated current [A]
    40
  • Rated fault current [A]
    0.1
  • Leakage current type
    A
  • Selective protection
    No
  • Short-circuit breaking capacity (Icw) [kA]
    6
  • Surge current capacity [kA]
    3
  • Additional equipment possible
    No
  • Construction size (in accordance with DIN 43880)
    4
  • Built-in depth [mm]
    79
  • Short-time delayed tripping
    No
  • Warranty
    5 Years
