Brand
NOARK
-
EAN Code
8592765117595
-
Mounting method
DIN rail (top hat rail) 35 mm
-
Width in number of modular spacings
3
-
Nominal voltage AC [V]
-
-
Max. continuous voltage AC [V]
-
-
Voltage protection level L-N [kV]
-
-
Voltage protection level N-PE [kV]
-
-
Construction size
3 modular spacing
-
Max. conductor cross section solid (solid, stranded) [mm²]
25
-
Max. conductor cross section flexible (fine-strand) [mm²]
25
-
With remote signalling contact
No
-
Integrated backup fuse
No
-
Signalling at the device
Optic
-
Power loss [W]
0.1
-
Number of poles (total)
3
-
Nominal voltage DC [V]
1000
-
System configuration DC
Yes
-
System configuration IT
No
-
System configuration TN
No
-
System configuration TN-C
No
-
System configuration TN-C-S
No
-
System configuration TN-S
No
-
System configuration TT
No
-
System configuration other
Yes
-
Lightning impulse current (10/350 µs) [kA]
6.25
-
Max. continuous voltage DC [V]
1000
-
Follow current extinguishing capability [kA]
-
-
Test class
Type 1 + 2
-
Exhausting
No
-
Energy-coordinated protection effect with regard to the terminal equipment
No
-
Warranty
5 Years
